LCD Transparent ScreenDetail
| Model No. | UESON-OLD01 |
| Brand | UESON |
| Pixel Pitch(mm) | 10 |
| Physical Density(dot/ m²) | 10,000 |
| LED Configuration | 3 in 1 |
| LED Type | SMD3535 |
| Module Resolution(dot/ w*h) | 32x16 |
| Module Size(mm*mm) | 320x160 |
| Standard Cabinet Size(mm*mm) | 960x960 |
| Cabinet Resolution(dot/ w*h) | 96x96 |
| Brightness(cd/ m²) | ≥6000 |
| Grey Scale | 14bit |
| Refresh Rate(Hz) | ≥1920 |
| Average Power Consumption(w/ m²) | 450~600 |
| Max Power Consumption(w/ m²) | ≥980 |
| Input Voltage(V) | AC 220V 50~60Hz/AC110V 60Hz |
| Viewing Angle(deg) | Horizontal ≥120°,Vertical ≥120° |
| Product Certification | ISO9001, CCC, ROHS, FCC, CE |
| Multi-Control Systems | Synchronous and asynchronous systems for option. |
| Multiple protection design | Soft silicone both around the led lamps and on the top of cabinet for imapct resistent; |
| OEM/ODM | Support |
