LCD Transparent ScreenDetail
| Model No. | UESON-TLS01 |
| Brand | UESON |
| Pixel Pitch | 2.97mm |
| Brightness | ≤1300 nits |
| Refresh Rate | ≥1920 Hz |
| Driving Method | 1/21 scan |
| Grey level | 65536 |
| Color Display | 281 trillion |
| LED Type | SMD2121 |
| IP Grade | IP30 / IP30 |
| Power consumption(Max/Average) | 960/288 W/sq.m |
| Module Size (mm) | 250X250mm |
| Cabinet Size(mm) | 500×500×80 mm |
| Cabinet Material | Magnesium alloy |
| Cabinet weight(kg) | 10 kg |
| Cabinet resolution | 168×168 Pixels |
| Pixel density | 112,896 Pixels/sq.m |
| Input AC power voltage | 96V-242V |
| Working temperature | -30℃ ~ 60℃ |
| Working temperature | 10%-95%RH |
| Working humidity | 10%-95%RH |
| Signal type(with video processor) | AV, S-Video, VGA, DVI, HDMI, SDI, DP |
| Control distance | HSYV: <100m; SMF: <10km |
| OEM/ODM | Support |
| Certification | ISO9001, CCC, ROHS, FCC, CE |
